Lowbed semi-trailers are specially designed to handle the transport of heavy-duty vehicles like tractors, buses, and specialized machinery, as well as rail cars, mining equipment, forestry machines, and construction vehicles such as excavators, bulldozers, loaders, pavers, and cranes. With their low center of gravity, these trailers offer improved stability and safety, making them ideal for carrying heavy and oversized cargo.
The low design also allows these trailers to transport tall cargo more easily, as it helps them navigate under overhead obstacles without issue. Their strong structure and stability make lowbed semi-trailers a top choice for safely moving high and heavy loads across various terrains
This vehicle is designed with features like automation, a low center of gravity, high strength, quick assembly, and easy loading. It’s capable of carrying oversized equipment, containers, and bulk cargo, making it suitable for a wide range of transport needs and applications.
Application: Hydraulic gooseneck low bed trailers are highly versatile and among the most commonly used types of low bed semi-trailers. These trailers are equipped with a hydraulic cylinder that detaches the gooseneck, allowing for easy loading and unloading. The hydraulic system adjusts the trailer’s height, lowering or raising it as needed to handle different types of cargo.
Advantages: A key advantage of front-loading on hydraulic gooseneck low bed trailers is improved safety when handling heavy equipment. Loading from the front is safer than using the rear or side, especially for large, heavy items. Rear loading often requires a long ladder structure, which increases the risk of the equipment slipping off or falling as it’s moved onto the cargo platform. Such falls can damage the equipment or cargo before transport even begins. Front-loading minimizes these risks, providing a safer and more secure loading process.
The Specification of starway 3 lines 6 axles lowbed semi trailer:
Dimensions: 18000mm*3000mm*18000mm (Standard Dimensions, Customizable)
Main Beam Material: Q345 / T700
Axles: 3 axles / 3lines 6 axles
Load Capacity:80-100 tons, Customizable
Detachable Goose neck: Available
Widened Parts: Available
Ladders: Mechanical spring / Hydraulic
Suspension: Heavy-duty Mechanical Suspension
Leaf Springs: 90mm*13mm*10pcs/90mm*16mm*10pcs
Tires: 12R22.5/8.25R20 (12)
King Pin: #50(2″)/#90(3.5″), JOST/other brands, replaceable
Landing Gear: 28 tons, two-speed, JOST/other brands
Paint: Electrophoretic paint for enhanced rust and corrosion resistance
Other Customizable Options: Rims, ABS, LED lights, reflective strips, etc.
